Manifold ceramic coat 140-160

I'm thinking about having my intake/exhaust manifold on my 71 164 ceramic coated. Are there any real benefits such a better fuel/air flow or is it just strictly cosmetic?








  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Manifold ceramic coat 140-160

    I did mine on my 1800E. I think as was said the head studs conduct heat to the manifold and it does not dissapate the heat I beleive. It looks good. The guy from www.performancecoatings.com explained it more like if you leave some thing in an oven it will go to the temp of the oven after long enough. I have an uncoated manifold but did not put on and to a side by side comparison of temp absorbsion/heat retension when under good cold ram air to see what the inside is like. It was done both inside and out. I did not have any throttle plate issues after the coating like I was afraid of. I did ceramic coat the header also. .

    Greg Bodner
    1970 1800E









  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Manifold ceramic coat 140-160

    It can be worthwhile if you have a modified B30 mainly from keeping the engine bay cooler rather that better flow. I'd only bother getting the exhaust done (unless you hace the intake and exhaust manifolds joined). If it's just a stock engine and you don't drive very hard then It won't gain anything for you apart from looks.
    --
    Alex Shevlin (Sydney): '71 142S, '72 144S, '81 244GLE, '81 244GL, '01 V70XC








  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Manifold ceramic coat 140-160

    Viper mentioned to me that inlet did not dissipate heat as well due to heatsink from head, this does not cool inlet air properly which is not what you want, looks great though.








  •   REPLY TO THIS MESSAGE    PRINT   SAVE

    Manifold ceramic coat 140-160

    One benefit: Coating the outside of the manifold will help reduce underhood temps.

    Best,

    Cameron
    Rose City








    •   REPLY TO THIS MESSAGE    PRINT   SAVE

      Manifold ceramic coat 140-160

      Which you can also do with a ceramic tape.








      •   REPLY TO THIS MESSAGE    PRINT   SAVE

        Manifold ceramic coat 140-160

        Several years ago our good friend Boris used some tape on his new header; unfortunately the header fell to pieces - literally - in a very short time (8 months I think... maybe 10... less than a year, though). We wondered how it could rust away so quickly and then learned that the tape not only trapped moisture that led to rust but also created a chemical reaction that accelerated the corrosion process. I don't know what chemical or adhesive was in the tape that leeched into the moisture that corroded the header that fell to pieces in Boris' car. I don't know why she swallowed the fly. La de da da...

        Clocks move slowest between 4 and 5pm on Fridays. yaaaaawwwn.

        Best,

        Cameron
        Rose City








        •   REPLY TO THIS MESSAGE    PRINT   SAVE

          Manifold ceramic coat 140-160

          Good point. I've seen a powder coat job that looked very good, but can't remember if the exhaust manifold was also done. Perhaps the tape will work if a primer/sealer is used before it is applied (and perhaps after), but again any cracks will let moisture in... At the end of the day, we should probably trust that Volvo did a good job for normal use.








          •   REPLY TO THIS MESSAGE    PRINT   SAVE

            Manifold ceramic coat 140-160

            I inquired about powder coating (this is some time ago, now) and was told that it can't stand up to exhaust gas temperatures. I don't know if it melts, or vaporizes, or what.

            I agree - Volvo did a fine job for normal use.

            Best,

            Cameron
            Rose City








      •   REPLY TO THIS MESSAGE    PRINT   SAVE

        Manifold ceramic coat 140-160

        I can't confirm it from my own experience, but I'm told that it's necessary to coat a header before taping it. Otherwise, moisture trapped under the tape will rust it out quickly.








  •   REPLY TO THIS MESSAGE Replies to this message will be emailed.    PRINT   SAVE

    Manifold ceramic coat 140-160

    If you coat it on the outside it won't rust but you might chip it and it
    will be very pretty except where it is chipped.

    If you coat it on the inside, that portion of the exhaust heat that normally
    dissipates through the manifold will go on to the headpipe and it will
    run hotter than normal. Since it is much thinner than the manifold you may
    shorten its life. It might give freer flow for a while but it will get dirty
    before long, just like your exhaust ports so you probably will only have a
    temporary gain if any.
    --
    George Downs, The "original" Walrus3, Bartlesville, Oklahoma







<< < > >>
